DRILLING & DEMOLITION 3

Ordering designation Diameter Working length Overall length Item number (1pc) Item number (8pc) Item number (16pc)
TE-CX 12/90 12 mm 830 mm 900 mm 2131130 1) 2022015 -
TE-CX 12/100 12 mm 930 mm 1000 mm 206555 1)
TE-CX 12/125 12 mm 1180 mm 1250 mm 2131131 1)
TE-CX 12.5/17 12.5 mm 100 mm 170 mm 409203 2022015 -
TE-CX 14/90 14 mm 830 mm 900 mm 2131132 1) - -
TE-CX 14/126 14 mm 1190 mm 1260 mm 2131133 1) - -
TE-CX 15/17 15 mm 100 mm 170 mm 409211 - -
TE-CX 15/27 15 mm 200 mm 270 mm 409212 - -
TE-CX 15/47 15 mm 400 mm 470 mm 409213 - -
TE-CX 16/17 16 mm 100 mm 170 mm 409214 2022019 -
TE-CX 16/90 16 mm 830 mm 900 mm 2131134 1) - -
TE-CX 16/128 16 mm 1210 mm 1280 mm 2131135 1) - -
TE-CX 17/22 17 mm 150 mm 220 mm 409219 - - 3
TE-CX 18/22 18 mm 150 mm 220 mm 2206745 - -
TE-CX 18/32 18 mm 250 mm 320 mm 2206746 - -
TE-CX 18/48 18 mm 410 mm 480 mm 2206747 - -
TE-CX 18/61 18 mm - 610 mm 2206748 - -
TE-CX 18/90 18 mm 830 mm 900 mm 2206749 - -
TE-CX 18/130 18 mm 1230 mm 1300 mm 2206750 1) - -
TE-CX 20/22 20 mm 150 mm 220 mm 2206751 - -
TE-CX 20/32 20 mm 250 mm 320 mm 2206617 - -
TE-CX 20/48 20 mm 410 mm 480 mm 2206618 - -
TE-CX 20/90 20 mm 540 mm 900 mm 427816 - -
TE-CX 22/27 22 mm 200 mm 270 mm 2206619 - -
TE-CX 22/48 22 mm 410 mm 480 mm 2206730 - -
TE-CX 24/27 24 mm 200 mm 270 mm 421971 - -
TE-CX 24/62 24 mm 550 mm 620 mm 427817 - -
TE-CX 25/27 25 mm 200 mm 270 mm 421977 - -
TE-CX 25/48 25 mm 410 mm 480 mm 422660 - -
TE-CX 26/48, 1”-18” 26 mm - 480 mm 2206736 1) - -
TE-CX 28/27 28 mm 200 mm 270 mm 421981 - -
TE-CX 28/48 28 mm 410 mm 480 mm 2206738 - -
1) For detailed stock availability and lead time information please contact your Hilti representative.

Please visit Hilti website for the latest item numbers and related products
Hammer drill bit set TE-CX

APPLICATIONS
● Drilling holes for metal anchors in reinforced and unreinforced
concrete
Order Now Watch Video
ADVANTAGES
● New solid carbide head for less wear and more holes with the
accuracy required for setting anchors
Ordering designation Package contents Sales pack Item number
quantity
TE-CX (6) M1 set 1x TE-CX 5/12, 2x TE-CX 6/17, 1x TE-CX 8/17, 1x TE-CX 10/17, 1x TE-CX 12/17 1 pc 411214
TE-CX (6) M2 set 2x TE-CX 6/17, 2x TE-CX 8/17, 2x TE-CX 10/17 1 pc 436095
TE-CX (6) M9 set 2x TE-CX 10/17, 2x TE-CX 12/17, 2x TE-CX 16/17 1 pc 436094

Please visit Hilti website for the latest item numbers and related products

Customer Hotline: Hong Kong 8228 8118, Macau 00800 8228 8118 Email: hksales@hilti.com
