Stone undercut anchor HSU-R

BASE MATERIALS Technical data
● Natural Stone Material composition Steel, A4 (SS316)
Head configuration Externally threaded
APPLICATIONS
● Stone cladding fixing

ADVANTAGES
● Easy installation
● Head marking for easy identification
Watch Video
● Gauge for checking drill hole geometry
● Setting mark to verify undercut completion

HSU-R (A4 stainless steel)

Ordering designation Anchor size Setting depth External thread length Sales pack quantity Item number
HSU-R M6x15/17 w/flange nut M6 15 mm 17 mm 250 pc 3583063 1)
HSU-R M8x15/17 w/flange nut M8 15 mm 17 mm 250 pc 3583064
HSU-R M8x21/17 w/flange nut M8 21 mm 17 mm 250 pc 3583065
1)
For detailed stock availability and lead time information please contact your Hilti representative.

8

HSU-R setting tools and accessories

Ordering designation Sales pack quantity Item number
Setting tool HSU ST-G M6 manual 1 pc 2179452 1)
Setting tool HSU ST-G M8 manual 1 pc 2179453
Hole inspection gauge HSU IG M6 1 pc 2179450 1)
Hole inspection gauge HSU IG M8 1 pc 2179451
Drill bit HSU CDB 11/13.5 conveyor 1 pc 2179456
Drill bit HSU CDB 13/15.5 conveyor 1 pc 2179457
Drilling tool HSU ADT G 220V advanced 1 pc 2193038 1)
1) For detailed stock availability and lead time information please contact your Hilti representative.
