Anchor channel HAC

APPLICATIONS Technical data
● Fastening curtain wall brackets Base material Concrete
● Fastening elevator guide rail brackets for lift car and Environmental conditions Indoor, damp conditions
counter-weight Material composition Steel, Hot-dip galvanized
● Fastening elevator slide door and landing sill
● Fastening M&E system with demanding requirements in terms of
flexibility and dust or noise reduction e.g. data center

ADVANTAGES
● Innovative V-shape provides high load resistance and close
edge distances
● Faster installation of building services than with traditional
anchor fastening method
● Dustless and noiseless fastening method
● Flexibility of use throughout the whole building life cycle
Order Now

HAC 40

Ordering designation Length, lch Number of anchors Anchor distance Standard embedment Sales pack Item number
depth, hef quantity
HAC-40 91/200 F 200 mm 2 150 mm 91 mm 1 pc 2122491 1)
HAC-40 91/350 F 350 mm 3 150 mm 91 mm 1 pc 2122493
HAC-40 91/550 F 550 mm 3 250 mm 91 mm 1 pc 2122495
HAC-40 91/1050 F 1050 mm 5 250 mm 91 mm 1 pc 2122497 1)
HAC-40 91/1300 F 1300 mm 6 250 mm 91 mm 1 pc 2122498 1)
HAC-40 91/1550 F 1550 mm 7 250 mm 91 mm 1 pc 2122499 1)
HAC-40 91/1800 F 1800 mm 8 250 mm 91 mm 1 pc 2122530 1)
HAC-40 91/2050 F 2050 mm 9 250 mm 91 mm 1 pc 2122531 1)
HAC-40 91/2300 F 2300 mm 10 250 mm 91 mm 1 pc 2122532 1)
HAC-40 91/5800 F 5800 mm 24 250 mm 91 mm 1 pc 2122536 1)
1) This is a non-stock item. For detailed lead time information please contact your Hilti representative.
Please visit Hilti website for the latest item numbers and related products
Order Now

HAC 50
Ordering designation Length, lch Number of anchors Anchor distance Standard embedment Sales pack Item number
depth, hef quantity
HAC-50 106/200 F 200 mm 2 150 mm 106 mm 1 pc 2122537 1)
HAC-50 106/350 F 350 mm 3 150 mm 106 mm 1 pc 2122539
HAC-50 106/450 F 450 mm 3 200 mm 106 mm 1 pc 2122540 1)
HAC-50 106/550 F 550 mm 3 250 mm 106 mm 1 pc 2122541 1)
HAC-50 106/1050 F 1050 mm 5 250 mm 106 mm 1 pc 2122543 1)
HAC-50 106/2300 F 2300 mm 10 250 mm 106 mm 1 pc 2122548 1)
HAC-50 106/5800 F 5800 mm 24 250 mm 106 mm 1 pc 2122553 1)
1) This is a non-stock item. For detailed lead time information please contact your Hilti representative.

Please visit Hilti website for the latest item numbers and related products
