P. 346
Hot-dip galvanized notched bolt HBC-C-N
Technical data
Environmental conditions Indoor, damp conditions
Tooth configuration Notched
Material, corrosion Steel, sherardized / hot-dip
galvanized
Order Now
Ordering designation Anchor size Useable thread length * Bolt length, l Sales pack Item number
quantity
HBC-C-N M16x60 8.8F M16 51 mm 60 mm 25 pc 2019736 1)
HBC-C-N M16x80 8.8F M16 71 mm 80 mm 25 pc 433479
HBC-C-N M16x100 8.8F M16 91 mm 100 mm 25 pc 2019737 1)
HBC-C-N M16x150 8.8F M16 140 mm 150 mm 25 pc 2019738 1)
HBC-C-N M20x60 8.8F M20 48 mm 60 mm 50 pc 434345 1)
HBC-C-N M20x80 8.8F M20 68 mm 80 mm 50 pc 2019739 1)
HBC-C-N M20x100 8.8F M20 88 mm 100 mm 50 pc 434346 1)
HBC-C-N M20x150 8.8F M20 138 mm 150 mm 25 pc 2019820 1)
1) This is a non-stock item. For detailed lead time information please contact your Hilti representative.
* Usable thread length measures the bolt length protruded after inserted the HBC-C into the HAC channel
Please visit Hilti website for the latest item numbers and related products
Stainless steel HBC-C
Technical data
Environmental conditions Outdoor
Material composition Steel, A4-50
Material, corrosion Steel, stainless
Order Now
Ordering designation Anchor size Useable thread length* Bolt length, l Sales pack Item number
quantity
HBC-C M12x50 50R M12 41 mm 50 mm 25 pc 433465 1)
HBC-C M12x80 50R M12 71 mm 80 mm 25 pc 433466 1)
HBC-C M16x60 50R M16 50 mm 60 mm 50 pc 433472 1)
HBC-C M16x80 50R M16 70 mm 80 mm 25 pc 433474 1)
1)
This is a non-stock item. For detailed lead time information please contact your Hilti representative.
* Usable thread length measures the bolt length protruded after inserted the HBC-C into the HAC channel
Please visit Hilti website for the latest item numbers and related products
