Anchor Channel – Corner Fixing HAC-CRFoS
APPLICATIONS Technical data
● Fastening curtain wall brackets in corner Environmental conditions Indoor, damp conditions
Material composition Steel, Hot-dip galvanized (channel)
ADVANTAGES
● No welding is required during the installation
● Design in pair for easy installation into formwork (traditional
welded corner has difficulty to be inserted into the rebar cage)
● New type of protective, environmentally friendly foam insert Order Now
(LDPE) and end caps seal the channel effectively, preventing
concrete slurry from entering the channel
Ordering designation Channel – Channel – Length, lch Number of Rebar Leg Rebar length, Effective Sales pack Item number
Profile Profile rebar Diameter lb embedment quantity
Height, hch Width, bch depth, hnom
HAC-40 369/350 F CRFoS 28 mm 40.9 mm 350 mm 3 Y10 325 mm 369 mm 1 pc 2062943 1)
1)
HAC-50 372/350 F CRFoS 31 mm 41.9 mm 350 mm 3 Y10 325 mm 372 mm 1 pc 2062965
HAC-60 415/350 F CRFoS 35.5 mm 43.4 mm 350 mm 3 Y12 360 mm 415 mm 1 pc 2070435 1)
HAC-70 444/350 F CRFoS 40 mm 45.4 mm 350 mm 3 Y16 380 mm 444 mm 1 pc 2070268
Please visit Hilti website for the latest item numbers and related products
